70 71 72 Chevy Chevelle Malibu Convertible Interior Master Bolt Kit 403 Pcs AMK

70 71 72 Chevy Chevelle Malibu Convertible Interior Master Bolt Kit 403 Pcs AMK

$257.49 USD
$0.00 USD $257.49 USD
Sale Sold out
1970 1971 1972 Chevy Chevelle Malibu Convertible Interior Master Bolt Kit 403 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's interior in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    70AN-CV 1 Master Interior Kit, 1970-72 Chevelle Convertible ** contains the sub-kits listed below ** 403
    G-5844 AIR OUTLET BEZELS (w AC) - Under Dash CHROME PH OV SEMS, NUTS 6
    G-5828 AIR OUTLET BEZELS (w AC) > DASH HX BT & ABT FLAT SEMS 9
    G-6644 AIR VENTS @ DOOR JAMB CHROME PH TRUSS WA TEK SCREWS 2
    G-5383 ARMREST PAD & BASE @ Fr DOORS CHROME PH RND & PH FLAT SCREWS 10
    G-5840 ASH TRAY RETAINER PH FLT TOP RNDWA SCREWS 4
    G-5789 CONSOLE > FLOOR HXWA & PN HD SCREWS 7
    G-5248 CONSOLE DOOR LOCK PH PN MS 1
    G-5794 CONSOLE DOOR, HINGE & STRIKER PH OV & PH PN SCREWS 11
    G-5790 CONSOLE END COVER CHROME PH OV SCREWS 4
    G-5791 CONSOLE MOULDINGS STAMPED NUTS ONLY 14
    G-5954 COURTESY LAMP, GLOVE BOX HX ABT FLAT SEMS 1
    G-5636 COURTESY LAMPS, UNDERDASH PH PN FLAT WA SEMS 2
    G-5822 DASH PAD RETAINING CLIPS, SCREWS 12
    G-4989 DIMMER SWITCH HXWA AB SCREWS 2
    G-5409 DOOR HANDLES (inside) - STD WIRE RETAINERS 2
    G-7559 DOOR JAMB WEDGES - CONVERTIBLE PH FLAT AB SCREWS 8
    G-5384 DOOR PANELS CLIPS, PLUGS (flexible!), PH OV AB SEMS 32
    G-4986 FUSE PANEL > FIREWALL #10 x 2 1/4 HXWA AB SCREWS w SEALER 2
    G-6585 GLOVE BOX BUMPERS RUBBER BUMPERS 2
    G-5836 GLOVE BOX DOOR & STOP PH PN & RNDWA SCREWS, PH OV SEMS 14
    G-5835 GLOVE BOX STRIKER RND WA SCREWS, SPRING NUTS 4
    G-6655 HEADREST ESCUTCHEONS & FABRIC RTNR CHROME PH OV AB & PH FLAT SCREWS 16
    G-5833 HEATER CONTROL & SUPPORT HXWA SCREWS, FLAT SEMS, SPR NUTS 7
    G-5478 HEATER or AC OUTLET (LH under dash) HXWA AB SCREWS 2
    G-5957 INSTRUMENT BEZEL > DASH HI-HX BT FLAT SEMS 8
    G-5826 INSTRUMENT PANEL ASSEMBLY HXWA ABT SCREWS 6
    G-5697 INSTRUMENT PANEL REINFORCEMENTS HX MS & BT SEMS, HXWA AB SCREWS 9
    G-5825 INSULATION > FIREWALL RUBBER RETAINERS 3
    G-6646 KICK PANELS w AC PH OV AB FINWA SEMS 3
    G-6652 KICK PANELS w/o AC HXWA SCREWS 10
    G-4621 MIRROR (INSIDE) > BRACKET CHROME SLOT OV SHLDR SCREW, BUSHING 2
    G-7540 MOULDING - CONVERTIBLE HEADER INSIDE SS/CHROME PH OV AB SCREWS 6
    G-6684 PILLAR MOULDINGS - ALL 68-69, 70-72 CV PH OV AB SEMS 6
    G-7541 QUARTER TRIM PANELS - CONVERTIBLE PH OV .50 SEMS, PH PN & PH RNDWA SCREWS 26
    G-5299 RADIO CONTROL SHAFTS & KNOBS Early 70F, SLOTTED NUTS, TEFLON WA'S 4
    G-4321 SCUFF PLATES @ DOOR OPENING SS/CHROME PH OV AB SCREWS 8
    G-6657 SEAT BACK (Fr) STOP BUMPERS PH PN AB SCREWS 4
    G-5398 SEAT BACK (Fr) STRIKERS (A-body bench) TRIM HX .62 CONI SEMS w PILOT 4
    G-5380 SEAT BACK (Rr) > FLOOR HX AB CONI TOOTH SEMS 2
    G-6654 SEAT BACK PANELS PH PN FLAT SEMS 6
    G-6161 SEAT BACK PIVOTS RETANING CLIPS 4
    G-7513 SEAT BACK RELEASE BEZELS (Bench only) CHROME PH OV AB SCEWS 4
    G-6675 SEAT BACK STRAP > SEAT BASE ROUNDED TRIM HX CONI SEMS 4
    G-7514 SEAT BELT BEZELS (Bench only) PH RNDWA AB SCREWS 4
    G-6955 SEAT PIVOT COVERS SPLIT DART METAL RETAINERS 2
    G-6656 SEAT SIDE PANELS PH RNDWA AB SCREWS 12
    G-6653 SEAT TRACKS > FLOOR HX CONI TOOTH SEMS (2), PERI KEPS 8
    G-4528 SHIFTER BOOT & BEZEL RETAINER - M/T w/o CONSOLE, HXWA AB SCREWS 10
    G-5893 SHIFTER BOOT RETAINER - M/T CONSOLE HXWA AB SCREWS 6
    G-5894 SHIFTER PLATE, LENS, SEAL - A/T CONSOLE HXWA AB CREWS, STAMPED NUTS 8
    G-5792 SHIFTER TRIM PLATE (console only) PH OV C SCREWS 6
    G-5928 STEERING COLUMN > DASH FLNG SCREWS, FLNG NUTS, CONI SEMS 7
    G-5823 STEERING COLUMN COVER > DASH CHROME PH OV FLUSH SEMS, SPR NUTS 8
    G-5926 STEERING COLUMN COVER > FIREWALL HXWA AB SCREWS 2
    G-5740 STEERING COLUMN SEAL RETAINER HXWA AB SCREWS, HX AB CONI SEMS 7
    G-5184 STEERING WHEEL COVER PH PN AB SCREWS, SPRING NUTS 4
    G-4998 STEERING WHEEL SHROUD PH PN EXT SEMS 4
    G-6670 SUN VISOR & MIRROR BRACKETS - CONV CHROME PH OV MS's, PH PN AB SCREWS 9
    G-5378 SUN VISOR CLAMPS CHROME SLOT FILL SCREWS 2
    G-4992 TURN SIGNAL LEVER PH PN AB SCREW 1
    G-6642 WEATHERSTRIP - QUARTER GLASS "U" .28 D PH RNDWA AB SCREWS 6
    G-5400 WINDOW CRANK HANDLES RETAINING CLIPS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 70AN-CV
