1971 1972 Monte Carlo 396/454 w/Disc Brakes Chassis Master Bolt Kit 356 Pcs AMK

1971 1972 Monte Carlo 396/454 w/Disc Brakes Chassis Master Bolt Kit 356 Pcs AMK

$315.17 USD
$0.00 USD $315.17 USD
Sale Sold out
1971 1972 Chevrolet Monte Carlo 396/454 w/Disc Front Brakes Chassis Master Bolt Kit 356 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's chassis in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    71MS-BB 1 Master Chassis Kit, 1971-72 BB Monte Carlo ** contains the sub-kits listed below ** 356
    G-5730 ACCELERATOR LEVER SUPPORT HXWA AB SCREWS 2
    G-5007 AXLE RETAINER PLATES GR-8 HX BOLTS, NUTS, SPLIT WA'S 24
    G-5863 BRAKE BOOSTER FLNG NUTS 4
    G-5259 BRAKE BOOSTER HOSE - 396/454 CLAMPS & NUT FOR TUBE BRACKET 3
    G-4642 BRAKE CABLES WIRE TYPE RETAINERS, HX NUTS 5
    G-6636 BRAKE CALIPER BRACKETS & SHIELDS HX BOLTS, LOCK NUTS 10
    G-5865 BRAKE DIST BLOCK (Fr) w PB HXWA T SCREWS 2
    G-4960 BRAKE DISTRIBUTION BLOCK (Rr) > BRKT HX BOLT 1
    G-5719 BRAKE HOSE BRACKETS (Fr) > FRAME HXWA AB SCREWS 2
    G-4958 BRAKE HOSE RETAINERS U-RETAINERS 3
    G-4612 CONTROL ARM CROSS SHAFT (UPR) RETAINERS, HX BOLTS "SSC", WA'S 12
    G-4608 CONTROL ARMS (LWR) POINTED BOLTS, LOCK NUTS 8
    G-4610 CONTROL ARMS (Rr) GR-8 POINTED BOLTS, LOCK NUTS 16
    G-5539 CONTROL ARMS (Rr) REINFORCEMENTS HARDENED FLAT WA'S 2
    G-4627 CONTROL ARMS (UPR) GR-8 KNURL BOLTS, LOCK NUTS, SHIMS 18
    G-5467 DIFFERENTIAL COVER - 12 BOLT 5/8" L SRTD FLNG SCREWS "E" 12
    G-4796 DRIVESHAFT, TH400 69 > 302, 350, BB. All 71 > 1.56" C-C HOLE STRAPS, FLNG BOLTS 6
    G-4967 ENGINE MOUNT THRU - V8 (69F & all 70-72) POINTED BOLTS, WA'S, LOCK NUTS 8
    G-4651 ENGINE MOUNTS > BLOCK - V8 HX SPLIT SEMS 6
    G-5877 ENGINE MOUNTS > FRAME - V8 (A only) GR-8 BOLTS, WA'S, NUTS 16
    G-5917 EXHAUST HANGERS - DUAL HXWA AB SCREWS 10
    G-5909 FUEL HOSES FLAT WOUND SPR CLAMPS (Black, Yell) 4
    G-5913 FUEL RETURN LINES - Pontiac & Chevy 396/454 FLAT WOUND SPRING CLAMPS (Red) 4
    G-5534 FUEL VAPOR CANISTER HXWA AB & CA SCREWS 3
    G-5805 FUEL VAPOR LINE HOSES FLAT WOUND SPR CLAMPS (Green, Yell) 10
    G-5734 GAS TANK SPECIAL BOLTS, HXWA SCREWS, U-NUTS 6
    G-4669 GREASE FITTINGS STRAIGHT STYLE 10
    G-5036 IDLER ARM > FRAME GR-8 HX BOLTS, WA'S, NUTS 6
    G-5144 MASTER CYLINDER FLNG NUTS 2
    G-4829 MASTER CYLINDER PUSH ROD > PEDAL RETAINING CLIP 1
    G-5864 PARKING BRAKE CONTROL > DASH HX CONI SEMS, FLNG NUTS, SEALER 6
    G-4668 PITMAN ARM > GEAR BOX HX NUT, SPLIT WA 2
    G-4586 SHOCKS (Fr) - LWR MOUNTING HXWA CA SCREWS, U-NUTS 8
    G-5859 SHOCKS (Rr) HXWA SCREWS, TK NUTS, SPLIT WA'S 12
    G-4694 SPEDOMETER CABLE > M/T, PG & some M38 1/4-20 X 5/8 HX SPLIT SEMS, RETAINER 2
    G-5141 STABILIZER BAR (Fr) BRACKETS HX TY-T SCREWS 4
    G-5481 STABILIZER BAR (Fr) END LINKS BOLTS, RETAINERS, BUSHINGS, NUTS 22
    G-5862 STABILIZER BAR (Rr) HX BOLTS, LOCK NUTS 8
    G-4354 STEERING GEAR "RAG" JOINT 12 PT BOLT ONLY 1
    G-5180 STEERING GEAR BOX > FRAME GR-8 HX BOLTS, FLAT WA'S 6
    G-5858 STEERING LINKAGE & BALL JOINTS SLOTTED NUTS, COTTER PINS 20
    G-4670 STEERING SHAFT > COUPLING REG & HVY NUTS, SPLIT WA'S 4
    G-5716 SUSPENSION BUMPER & BRACKET (Rr) HX BOLTS, NUTS, SPLIT WA'S 7
    G-4596 SUSPENSION BUMPERS (Fr) HX NUTS 2
    G-4169 TRANS CROSSMEMBER HX BOLTS, WA'S (RH SIDE), NUTS 14
    G-5886 TRANS INSULATOR - TH400 (also does All) HX BOLTS, FLAT & SPLIT WA'S 14
    G-6581 WHEEL CYLINDERS (2) HX INT TOOTH SEMS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 71MS-BB
