1969 Pontiac GTO Convertible Interior Master Bolt Kit 363 Pcs - AMK

1969 Pontiac GTO Convertible Interior Master Bolt Kit 363 Pcs - AMK

$299.99 USD
$0.00 USD $299.99 USD
Sale Sold out
1969 Pontiac GTO Convertible Interior Master Bolt Kit 363 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's interior in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    69TN-CV 1 Master Interior Kit, 1969 GTO Convertible ** contains the sub-kits listed below ** 363
    G-7553 AC AIR OUTLET DUCT @ FLOOR PH PN AB SCREWS, FLAT WA'S 5
    G-7533 AIR OUTLET ADAPTERS > DASH PAD .75 D 10-24 STAMPED NUTS 11
    G-5383 ARMREST PAD & BASE @ Fr DOORS CHROME PH RND & PH FLAT SCREWS 10
    G-7529 ASH TRAY RETAINER CHROME PH RNDWA SCREWS, SPRG NUTS 7
    G-7534 CONSOLE & FLOOR BRACKETS HXWA SCREWS, FLAT WA 13
    G-5281 CONSOLE BRACKET > A/T SHIFTER HX BOLTS 3
    G-7536 CONSOLE COMPARTMENT & HINGE HXWA & RNDWA AB SCREWS 7
    G-6587 CONSOLE DOOR BUMPERS .31 D X .15 H FLAT TOP RUBBER BUMPERS 2
    G-7535 CONSOLE TRIM PLATE - A/T .56 D #10 STAMPED NUTS 4
    G-7140 COURTESY LAMPS, UNDERDASH PH PN AB SCREWS, STAMPED NUT 6
    G-7521 DASH PAD HX SEMS, SCREWS, STAMPED & NYLON NUTS 13
    G-4989 DIMMER SWITCH HXWA AB SCREWS 2
    G-5409 DOOR HANDLES (inside) - STD WIRE RETAINERS 2
    G-7559 DOOR JAMB WEDGES - CONVERTIBLE PH FLAT AB SCREWS 8
    G-5384 DOOR PANELS CLIPS, PLUGS (flexible!), PH OV AB SEMS 32
    G-4986 FUSE PANEL > FIREWALL #10 x 2 1/4 HXWA AB SCREWS w SEALER 2
    G-6585 GLOVE BOX BUMPERS RUBBER BUMPERS 2
    G-7526 GLOVE BOX DOOR & STOP (69-72 combo) PH RNDWA SCREWS, SPR NUTS, RIVETS, PLUGS 16
    G-7524 GLOVE BOX LINER & STRIKER RNDWA AB SCREWS 10
    G-6655 HEADREST ESCUTCHEONS & FABRIC RTNR CHROME PH OV AB & PH FLAT SCREWS 16
    G-7518 HEATER CONTROL & SUPPORT > DASH .50 D 10-24 STMPD NUTS, SCREWS 6
    G-5478 HEATER or AC OUTLET (LH under dash) HXWA AB SCREWS 2
    G-7546 INSTRUMENT CLUSTER & CLOCK > BODY HXWA AB SCREWS 8
    G-7523 INSTRUMENT PANEL MOULDINGS #10 X .56 D STAMPED NUTS 3
    G-7504 INSULATION > FIREWALL RUBBER RETAINERS 5
    G-5762 KICK PANELS w AC PH OV AB FLUSH SEMS 4
    G-6652 KICK PANELS w/o AC HXWA SCREWS 10
    G-4621 MIRROR (INSIDE) > BRACKET CHROME SLOT OV SHLDR SCREW, BUSHING 2
    G-7540 MOULDING - CONVERTIBLE HEADER INSIDE SS/CHROME PH OV AB SCREWS 6
    G-6684 PILLAR MOULDINGS - ALL 68-69, 70-72 CV PH OV AB SEMS 6
    G-7541 QUARTER TRIM PANELS - CONVERTIBLE PH OV .50 SEMS, PH PN & PH RNDWA SCREWS 26
    G-5318 RADIO CONTROL SHAFTS SPECIAL THIN HX NUTS 2
    G-4321 SCUFF PLATES @ DOOR OPENING SS/CHROME PH OV AB SCREWS 8
    G-6657 SEAT BACK (Fr) STOP BUMPERS PH PN AB SCREWS 4
    G-5398 SEAT BACK (Fr) STRIKERS (A-body bench) TRIM HX .62 CONI SEMS w PILOT 4
    G-5380 SEAT BACK (Rr) > FLOOR HX AB CONI TOOTH SEMS 2
    G-6654 SEAT BACK PANELS PH PN FLAT SEMS 6
    G-6161 SEAT BACK PIVOTS RETANING CLIPS 4
    G-7513 SEAT BACK RELEASE BEZELS (Bench only) CHROME PH OV AB SCEWS 4
    G-6658 SEAT BACK RELEASE ESCUTCHEONS CHROME PH OV & PN AB SCREWS 8
    G-6675 SEAT BACK STRAP > SEAT BASE ROUNDED TRIM HX CONI SEMS 4
    G-7514 SEAT BELT BEZELS (Bench only) PH RNDWA AB SCREWS 4
    G-6955 SEAT PIVOT COVERS SPLIT DART METAL RETAINERS 2
    G-6656 SEAT SIDE PANELS PH RNDWA AB SCREWS 12
    G-6653 SEAT TRACKS > FLOOR HX CONI TOOTH SEMS (2), PERI KEPS 8
    G-7537 STEERING COLUMN & BRACES > DASH HX SEMS, NUTS, COPPER PLATE SCREWS 8
    G-7528 STEERING COLUMN COVER > DASH PH PN AB SCREWS, NYLON NUTS 4
    G-5926 STEERING COLUMN COVER > FIREWALL HXWA AB SCREWS 2
    G-5630 STEERING COLUMN SEAL RETAINER HXWA AB SCREWS 7
    G-7001 STEERING WHEEL SHROUD PN PN AB SCREWS 3
    G-6670 SUN VISOR & MIRROR BRACKETS - CONV CHROME PH OV MS's, PH PN AB SCREWS 9
    G-5378 SUN VISOR CLAMPS CHROME SLOT FILL SCREWS 2
    G-4992 TURN SIGNAL LEVER PH PN AB SCREW 1
    G-6642 WEATHERSTRIP - QUARTER GLASS "U" .28 D PH RNDWA AB SCREWS 6
    G-5400 WINDOW CRANK HANDLES RETAINING CLIPS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 69TN-CV
