1969 Pontiac Firebird Convertible w/Standard Interior Master Bolt Kit 328 Pcs

1969 Pontiac Firebird Convertible w/Standard Interior Master Bolt Kit 328 Pcs

$236.89 USD
$0.00 USD $236.89 USD
Sale Sold out
1969 Pontiac Firebird Convertible w/Standard Interior Master Bolt Kit 328 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's interior in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    69HN-CVS 1 Master Interior Kit, 1969 Firebird Convertible STD ** contains the sub-kits listed below ** 328
    G-4704 AIR OUTLET BEZELS (w AC) > DASH PH OV & PH PN SCREWS, SPRING NUTS 8
    G-5135 AIR VENTS @ DOOR JAMB .28 D PH TRUSSWA AB SCREWS 2
    G-5383 ARMREST PAD & BASE @ Fr DOORS CHROME PH RND & PH FLAT SCREWS 10
    G-7021 ASH TRAY BUMPERS RUBBER BUMPERS 2
    G-7020 ASH TRAY RETAINER CHROME PH RNDWA SCREWS, SPRG NUTS 6
    G-7029 COLUMN SHIFT LEVER 7/32 X 15/16" ROLL PIN 1
    G-4730 CONSOLE > FLOOR PH TRUSS SCREWS, RIVET NUTS, NUTS 6
    G-7036 CONSOLE APPLIQUE - AT END PH PN AB SCREWS 4
    G-7030 CONSOLE APPLIQUE - SURROUNDING SHIFTER HX NUTS (3 XTRA FOR M/T), SPACERS 11
    G-4731 CONSOLE BRACKET & TOP FRAME HXWA MS & PH OV SCREWS, SPR NUTS 9
    G-5281 CONSOLE BRACKET > A/T SHIFTER HX BOLTS 3
    G-4732 CONSOLE DOOR & HINGE PH PN M SCREWS 8
    G-6587 CONSOLE DOOR BUMPERS .31 D X .15 H FLAT TOP RUBBER BUMPERS 2
    G-5636 COURTESY LAMPS, UNDERDASH PH PN FLAT WA SEMS 2
    G-5392 DASH PAD PH PN AB SCREWS, STAMPED NUTS 9
    G-4989 DIMMER SWITCH HXWA AB SCREWS 2
    G-5409 DOOR HANDLES (inside) - STD WIRE RETAINERS 2
    G-5384 DOOR PANELS CLIPS, PLUGS (flexible!), PH OV AB SEMS 32
    G-4986 FUSE PANEL > FIREWALL #10 x 2 1/4 HXWA AB SCREWS w SEALER 2
    G-6585 GLOVE BOX BUMPERS RUBBER BUMPERS 2
    G-7024 GLOVE BOX DOOR PH PN AB FLAT & MS SEMS, SPRING NUTS 8
    G-7023 GLOVE BOX LINER PH PN AB FLAT SEMS 4
    G-4943 GLOVE BOX STRIKER PN PN AB FLAT SEMS 2
    G-7022 GRAB BAR (on dash) 10-24 CONI KEPS NUTS 2
    G-7018 HEATER CONTROL & SUPPORT HXWA SCREWS, FLAT WASHER 6
    G-6997 HORN BUTTON w T/A, WOODGRAIN, FORMULA PH PB BT SCREWS 3
    G-7026 INSTRUMENT COVER (surrounds gauges) PH AB SCREWS, FLAT WA'S, STAMPED NUT 18
    G-7027 INSTRUMENT COVER PANEL BRACKETS PH PN AB SCREWS 3
    G-4617 INSULATION > FIREWALL RUBBER RETAINERS 4
    G-5390 KICK PANELS CHROME PH OV FINISH WA SEMS .50 D 10
    G-4621 MIRROR (INSIDE) > BRACKET CHROME SLOT OV SHLDR SCREW, BUSHING 2
    G-5435 MOULDINGS - CONVERTIBLE HEADER SS/CHROME PH OV AB SCREWS 5
    G-5388 PILLAR MOULDINGS - CONVERTIBLE PH OV AB SCREWS 4
    G-5421 QUARTER TRIM PANELS - CONVERTIBLE CHROME PH OV AB FINWA SEMS .50 D 8
    G-7037 RADIO BRACKET HXWA AB SCREWS, SPRG NUTS 4
    G-4821 RADIO CONTROL SHAFTS & KNOBS SPECIAL THIN HX NUTS, SPRING WA'S 4
    G-5415 ROCKER PANEL COVER PLATES PH PN AB SCREWS 8
    G-4321 SCUFF PLATES @ DOOR OPENING SS/CHROME PH OV AB SCREWS 8
    G-5375 SEAT BACK (Fr) STOP BUMPERS CHROME PH PN AB SCREWS 2
    G-5398 SEAT BACK (Fr) STRIKERS (A-body bench) TRIM HX .62 CONI SEMS w PILOT 4
    G-5380 SEAT BACK (Rr) > FLOOR HX AB CONI TOOTH SEMS 2
    G-5381 SEAT BACK PANELS PH PN AB .50 FLAT SEMS, PH OV AB SCREWS 8
    G-6161 SEAT BACK PIVOTS RETANING CLIPS 4
    G-5376 SEAT BACK STOP CABLE (used @ RH only) PH WAFER MS SHLDR SCREWS 2
    G-5379 SEAT PIVOT COVERS SPLIT DART METAL RETAINERS 4
    G-5148 SEAT TRACKS > FLOOR HX CONI TOOTH .88 D SEMS 8
    G-5165 SHIFTER BOOT PLATE w/o CONSOLE CHROME PH OV AB SCREWS 4
    G-7032 SHIFTER CABLE SEAL RETAINER (console) HXWA AB SCREWS 3
    G-7035 SHIFTER SEAL RETAINER - M/T CONSOLE PH PN AB SCREWS 4
    G-5098 SPEAKERS & GRILLES @ KICK PANELS PH OV AB SCREWS, SPRING NUTS 16
    G-7034 STEERING COLUMN & BRACES > DASH HX SEMS, FLNG NUTS, COPPER PLATE SCREWS 10
    G-7028 STEERING COLUMN COVER (LWR) HX AB 1.0 FLAT SEMS SCREWS 2
    G-7025 STEERING COLUMN COVER > DASH PH PN AB SCREWS 2
    G-4975 STEERING COLUMN SEAL RETAINER HX AB FLAT SEMS, HXWA AB SCREWS 6
    G-7001 STEERING WHEEL SHROUD PN PN AB SCREWS 3
    G-5422 SUN VISOR & MIRROR BRACKETS - CONV SS/CHROME PH OV MS SCREWS 7
    G-5378 SUN VISOR CLAMPS CHROME SLOT FILL SCREWS 2
    G-4992 TURN SIGNAL LEVER PH PN AB SCREW 1
    G-5389 WEATHERSTRIP, QUARTER GLASS "U" .28 D PH RNDWA AB SCREWS 4
    G-5400 WINDOW CRANK HANDLES RETAINING CLIPS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 69HN-CVS
