1968 Chevy Chevelle 307/327 w/Disc Brakes Chassis Master Bolt Kit 367 Pcs - AMK

1968 Chevy Chevelle 307/327 w/Disc Brakes Chassis Master Bolt Kit 367 Pcs - AMK

$308.99 USD
$0.00 USD $308.99 USD
Sale Sold out
1968 Chevrolet Chevelle 307/327 w/Disc Front Brakes Chassis Master Bolt Kit 367 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's chassis in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    68AS-DCSB 1 Master Chassis Kit, 1968 Chevelle Disc Brake SB ** contains the sub-kits listed below ** 367
    G-5730 ACCELERATOR LEVER SUPPORT HXWA AB SCREWS 2
    G-5007 AXLE RETAINER PLATES GR-8 HX BOLTS, NUTS, SPLIT WA'S 24
    G-4738 BRAKE BOOSTER HX NUTS, SPLIT WA'S 8
    G-4740 BRAKE BOOSTER HOSE FLAT WOUND SPRING CLAMPS (Black) 2
    G-4642 BRAKE CABLES WIRE TYPE RETAINERS, HX NUTS 5
    G-5938 BRAKE CALIPER BRACKETS & SHIELDS SPECIAL GR-8 HX BOLTS, LOCK NUTS 10
    G-6045 BRAKE CALIPERS > BRACKET GR-8 HX BOLTS, SPLIT WA'S 8
    G-5619 BRAKE DISTRIBUTION BLOCK HXWA C SCREW 1
    G-6215 BRAKE HOSE > CALIPER BRACKET U-RETAINERS 2
    G-4641 BRAKE HOSE RETAINERS U-RETAINERS 4
    G-5888 CLUTCH BELLCRANK BRACKET > FRAME HXWA C SCREWS 2
    G-4612 CONTROL ARM CROSS SHAFT (UPR) RETAINERS, HX BOLTS "SSC", WA'S 12
    G-4608 CONTROL ARMS (LWR) POINTED BOLTS, LOCK NUTS 8
    G-4610 CONTROL ARMS (Rr) GR-8 POINTED BOLTS, LOCK NUTS 16
    G-4627 CONTROL ARMS (UPR) GR-8 KNURL BOLTS, LOCK NUTS, SHIMS 18
    G-5466 DIFFERENTIAL COVER - 10 BOLT 7/8" L HXWA MACHINE SCREWS 10
    G-5467 DIFFERENTIAL COVER - 12 BOLT 5/8" L SRTD FLNG SCREWS "E" 12
    G-4629 DRIVESHAFT > REAR KNUCKLE U-BOLTS, NUTS, WA'S 10
    G-5723 ENGINE MOUNT THRU - SB (A only) HX BOLTS, WA'S, NUT 5
    G-4651 ENGINE MOUNTS > BLOCK - V8 HX SPLIT SEMS 6
    G-4587 ENGINE MOUNTS > FRAME - V8 (A only) HX BOLTS, WA'S, NUTS 28
    G-5573 EXHAUST HANGERS - DUAL HXWA C SCREWS, RETAINERS 10
    G-5533 FUEL HOSES, 283-4V, 307, 327 (All 68-69A) FLAT WOUND SPRING CLAMPS (Green) 4
    G-5736 FUEL VAPOR LINE HOSES & CLIP HXWA SCREW, SPR CLAMPS (Blk & Red) 3
    G-5734 GAS TANK SPECIAL BOLTS, HXWA SCREWS, U-NUTS 6
    G-4669 GREASE FITTINGS STRAIGHT STYLE 10
    G-4265 IDLER ARM > FRAME GR-8 HX BOLTS, WA'S, NUTS 6
    G-4741 MASTER CYL BALANCE VALVE w DISC @ MASTER CYLINDER, HX EXT SEMS 1
    G-4635 MASTER CYLINDER HX NUTS, SPLIT WA'S 4
    G-4829 MASTER CYLINDER PUSH ROD > PEDAL RETAINING CLIP 1
    G-5489 PARKING BRAKE CONTROL > DASH HX SPLIT SEMS, FLNG NUTS, SEALER 5
    G-4668 PITMAN ARM > GEAR BOX HX NUT, SPLIT WA 2
    G-7119 SHOCKS (Fr) - LWR MOUNTING HXWA MS's, J-NUTS 8
    G-5483 SHOCKS (Rr) BOLTS, LOCK NUTS, FLAT & SPLIT WA'S 16
    G-4694 SPEDOMETER CABLE > M/T, PG & some M38 1/4-20 X 5/8 HX SPLIT SEMS, RETAINER 2
    G-4628 STABILIZER BAR (Fr) BRACKETS HXWA C SCREWS 4
    G-5481 STABILIZER BAR (Fr) END LINKS BOLTS, RETAINERS, BUSHINGS, NUTS 22
    G-4354 STEERING GEAR "RAG" JOINT 12 PT BOLT ONLY 1
    G-5180 STEERING GEAR BOX > FRAME GR-8 HX BOLTS, FLAT WA'S 6
    G-4615 STEERING LINKAGE & BALL JOINTS SLOTTED NUTS, COTTER PINS 20
    G-4670 STEERING SHAFT > COUPLING REG & HVY NUTS, SPLIT WA'S 4
    G-5716 SUSPENSION BUMPER & BRACKET (Rr) HX BOLTS, NUTS, SPLIT WA'S 7
    G-4596 SUSPENSION BUMPERS (Fr) HX NUTS 2
    G-4169 TRANS CROSSMEMBER HX BOLTS, WA'S (RH SIDE), NUTS 14
    G-4604 TRANS INSULATOR (exc 69 TH400) HX BOLTS, FLAT & SPLIT WA'S 12
    G-6581 WHEEL CYLINDERS (2) HX INT TOOTH SEMS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 68AS-DCSB
