1966 Pontiac GTO Convertible Interior Master Bolt Kit 330 Pcs - AMK

1966 Pontiac GTO Convertible Interior Master Bolt Kit 330 Pcs - AMK

$245.99 USD
$0.00 USD $245.99 USD
Sale Sold out
1966 Pontiac GTO Convertible Interior Master Bolt Kit 330 Pcs - AMK
  • The authentic hardware you need to properly reassemble your car's interior in one package!
  • Master kits will provide about 85% of the fasteners found on your vehicle.
  • We highly recommend that you reference the Factory Assembly Manuals!
  • PART # APPLICATION NOTES PCS
    66TN-CV 1 Master Interior Kit, 1966 GTO Convertible ** contains the sub-kits listed below ** 330
    G-7555 AIR OUTLET CONTROL CABLES LOW RNDWA AB SCREWS 4
    G-6673 ARMREST PAD & BASE @ Fr DOORS PH FLAT B & PH RND A SCREWS 8
    G-7488 ASH TRAY RETAINER PH RND WA AB, SPRNG NUTS, FLAT WA 6
    G-7494 CONSOLE > FLOOR PH OV & HXWA AB SCREWS 8
    G-7496 CONSOLE DOOR & HINGE PH PN SCREWS, TOOTH WA'S 8
    G-7588 CONSOLE DOOR BUMPERS .50 D X .25 H BUMPERS 2
    G-7493 CONSOLE LAMP LENS PH OV AB SCREWS 2
    G-7495 CONSOLE TOP MOULDING NUTS, HXWA & RNDWA SCREWS (M/T ONLY) 9
    G-7483 COURTESY LAMPS, UNDERDASH PH PN AB SCREWS, FLAT WA'S 4
    G-7490 DASH PAD S-CLIPS, NUTS, PH OV SCREWS, SPRG NUTS 13
    G-4989 DIMMER SWITCH HXWA AB SCREWS 2
    G-5409 DOOR HANDLES (inside) - STD WIRE RETAINERS 2
    G-7559 DOOR JAMB WEDGES - CONVERTIBLE PH FLAT AB SCREWS 8
    G-6667 DOOR PANELS CLIPS, PLUGS (flexible!), PH OV AB SEMS 28
    G-7508 FILLER PANEL - CONVERT BEHIND Rr SEAT CHROME PH RNDWA AB SCREWS 10
    G-4986 FUSE PANEL > FIREWALL #10 x 2 1/4 HXWA AB SCREWS w SEALER 2
    G-4023 GLOVE BOX BUMPERS .24 D X .12 H FLAT TOP BUMPERS 2
    G-5470 GLOVE BOX DOOR, LINER & STRIKER RNDWA AB SCREWS 8
    G-4942 GRAB BAR (on dash) .50 D 10-24 STAMPED NUTS 2
    G-7485 HEATER CONTROL & SUPPORT > DASH .56 D #10 STMPD NUTS, HXWA SCREWS 6
    G-5478 HEATER or AC OUTLET (LH under dash) HXWA AB SCREWS 2
    G-7482 INSTRUMENT CLUSTER > BEZEL INCLUDES BRACKET SCREWS 12
    G-7480 INSTRUMENT CLUSTER BEZEL > DASH PH OV AB SCREWS, SPRG NUTS, NYLON NUTS 18
    G-7486 INSTRUMENT PANEL NAMEPLATE "GTO" .56 D #10 STAMPED NUTS 3
    G-7504 INSULATION > FIREWALL RUBBER RETAINERS 5
    G-6686 KICK PANELS CHROME PH OV FINISH WA SEMS, .50" D 4
    G-4621 MIRROR (INSIDE) > BRACKET CHROME SLOT OV SHLDR SCREW, BUSHING 2
    G-7507 MOULDING - CONVERTIBLE HEADER SS/CHROME PH OV AB SCREWS 6
    G-6668 MOULDINGS @ DOOR/QTER TRIM PANEL TOPS PH FLAT AB SCREWS 18
    G-7506 QUARTER TRIM PANELS - CONVERTIBLE PH OV .50 SEMS, PH PN & PH RNDWA SCREWS 20
    G-4821 RADIO CONTROL SHAFTS & KNOBS SPECIAL THIN HX NUTS, SPRING WA'S 4
    G-4321 SCUFF PLATES @ DOOR OPENING SS/CHROME PH OV AB SCREWS 8
    G-6657 SEAT BACK (Fr) STOP BUMPERS PH PN AB SCREWS 4
    G-5380 SEAT BACK (Rr) > FLOOR HX AB CONI TOOTH SEMS 2
    G-6660 SEAT BACK PANELS PH PNWA FLAT TOP SCREWS 4
    G-6161 SEAT BACK PIVOTS RETANING CLIPS 4
    G-6955 SEAT PIVOT COVERS SPLIT DART METAL RETAINERS 2
    G-6661 SEAT SIDE PANELS CHROME PH OV AB SCREWS 12
    G-6653 SEAT TRACKS > FLOOR HX CONI TOOTH SEMS (2), PERI KEPS 8
    G-7556 SHIFTER "PORCH" (M/T TUNNEL ADAPTER) HXWA AB SCREWS 6
    G-7499 SHIFTER BEZEL - M/T CONSOLE #10 X .56 D STAMPED NUTS 4
    G-7557 SHIFTER BOOT RETAINER - M/T CONSOLE HXWA AB SCREWS 2
    G-7502 SHIFTER LEVER PLATE (MT w/o console) CHROME PH PN AB 4
    G-5494 STEERING COLUMN > DASH HX PP CONI SEMS, FLNG NUTS 4
    G-7550 STEERING COLUMN COVER > DASH PH OV AB SCREWS, SPRG NUTS 4
    G-5924 STEERING COLUMN COVER > FIREWALL PLASTIC RETAINERS 2
    G-5496 STEERING COLUMN SEAL RETAINER HI-HXWA AB SCREWS, FLAT WA'S 8
    G-6669 SUN VISOR & MIRROR BRACKETS - CONV CHROME PH OV MS's, PH OV AB SCREWS 7
    G-5378 SUN VISOR CLAMPS CHROME SLOT FILL SCREWS 2
    G-7505 TURN SIGNAL LEVER 8-32 x 1/2 PH PN MS 1
    G-6666 VENT WINDOW CHANNEL > DOOR #10 X 2 1/2" SS/CHROME PH OV SCREWS 2
    G-6677 WEATHERSTRIP - QUARTER GLASS "U" PH FLT AB SCREWS 4
    G-7512 WINDLACE END CAPS @ QUARTER CHROME RNDWA AB SCREWS 4
    G-5400 WINDOW CRANK HANDLES RETAINING CLIPS 4
  • This product will be made to order and drop shipped from the manufacturer and will ship in 1-7 business days.
  • If you have any questions, please do not hesitate to message us. We are very responsive and look forward to helping you in any way we can!
  • Proudly made in the USA by AMK: 66TN-CV
